Stitch typ

Single needle ,lockstitch

Sewing area

(X) 13mmx (Y) 60mm

(X) 200mmx (Y) 100mm

(X) 250mmx (Y) 160mm

Max. Sewing speed

2500rpm

2000rpm

2000rpm

Sewing speed selection

2500rpm

2000rpm

2000rpm

Feeding system

Intermittent or Continuous

Stitch length

0.1~ 12.7mm (Minimum resolution 0.1mm)

Scale- up/down function

10~ 200% for each X .& Y. Axis ( 0.1 % increment/step )

Max. Number of stitches

8000 stitches /pattern

Needle

DPx17#8

Hook

Large size shuttle hook

Work holder lift

525 ~ 30mm

18mm

18mm

Stepping foot lift

20mm

Stepping foot stroke

4~ 10mm

Presser foot system

Magnetic

Pneumatic

Pneumatic

Main drving motor

400W Driect servo motor                                                                500W Driect servo motor

Power

200V1 Phase/380V 3 phase (土10% ) 600A

Mass

120Kg

156Kg

180Kg

Measurement

1,200mm ( W) x 860mm

(D)X 1,170mm(H)

1 ,200mm ( W ) x 1,100mm

(D)X 1,170mm (H )

1,200mm (W ) x 1,150mm

(D) X 1,170mm (H)
